Build Your Own

Wiring Harness for Yamaha Pacifica

Regular price: $0.00 CAD
Regular price
Sale price: $0.00 CAD

Shipping calculated at checkout.

Features:

Comprehensive Wiring Upgrade
Crystal Clear Tone (Treble Bleed)
Smooth Tone Control
Layout Flexibility
Solder-less Install

This set uses US spec upgrade parts. Ream holes to 9.54mm, and get new knobs to fit

Solderless Wiring Harness for Pacifica® Yamaha®

Upgrade your Pacifica® Yamaha® with a professionally built wiring harness featuring premium US-spec electronics, solderless pickup connections and flexible control options. Designed specifically for Yamaha® -style guitars, this harness gives you a cleaner installation and makes future pickup changes much easier.

Comprehensive Wiring Upgrade
Crystal Clear Tone (Treble Bleed)
Smooth Tone Control
Layout Flexibility
Solder-less Install

This set uses US spec upgrade parts. Ream holes to 9.54mm, and get new knobs to fit

Product Details

Description

Super Easy, Solder-less Install
All Obsidian® Pro-Wired™ Electronics are super easy to install, and allow for solder-less pickup changes with Obsidian® Plug, Play & Enjoy connectors.

Features

CRYSTAL CLEAR TONE (Treble Bleed)

Retain clarity at lower volumes. To make your tone crystal clear at lower volumes we include an Obsidian® Custom spec treble bleed mod. This prevents tone 'muddiness' at low volumes by allowing high frequencies to pass along a separate path to your amp, rather than being stopped short by the increasing resistance at the volume control.

SMART VOLUME CONTROL (Switchable 250k / 500k)

Easily select between 250k & 500k to optimize the treble balance for your setup

250k = Warmer / balanced treble (great for single coils)
500k = Brighter / retains treble (great for humbuckers & P90s)

SMOOTH TONE CONTROL

Add a custom designed master tone control using our ObsidianWire designed, CTS built IGNEOS™ pots, for a smooth and useable tone control taper.

Upgrade Options

DUAL TUNED SC (COIL SPLIT)

Turn your humbucker(s) in to a single coil, and back again. To add true versatility to your guitar we build in DUAL TUNED SC, to split your humbucker(s) to a single-coil for lower output, more dynamic tones.

To keep your single coils sound full and vibrant, we use Tuned 'partial split' technology, for higher output sound with fuller mids, than is possible with a full split.

Requires split coil compatible humbuckers

Specs

More Info

Shipping

US Based Fulfillment:

We ship from Michigan, USA.

Please note that due to the way in-state taxes are collected, we cannot ship website orders within Michigan state. If you are based in Michigan, please order through our Amazon store here as this is set up to collect the required sales taxes. Apologies for any inconvenience caused.

Canada

Shipping method:	Business days:	Price (US$ Aprox.)
ECONOMY POST	7 - 21	8.99
DHL PACKET	5 - 10	13.99

Taxes and duties

Obsidian® DOES NOT pay duties, taxes or customs clearance charges.

Duties and taxes charged by your local customs agency, will be your own responsibility.

If you live outside the USA, we recommend checking with your own country's customs agency what these may be prior to ordering.

If you are concerned, consider ordering from dealer near you

International Dealers

Yamaha® Compatibility & Installation Requirements

Important: Yamaha uses 'Metric' size parts, but the upgrade is worth it

Check hole spacing & layout carefully
Get new US spec knobs.
Ream 'Metric' holes to 9.54mm // 3/8" for the high grade electronics.

Please check your specific guitar model, and ObsidianWire® product selection carefully, to ensure a good fit.

Yamaha® Install Instructions

The Flex-Series™
Made to work with compatible Flex-Series™ parts
The ObsidianWire Flex-Series™ is a complete wiring system made to work with other compatible Flex-Series™ parts. This will not work with parts that do not belong to a compatible Flex-Series™ system.
- Volume Controls
- Tone Controls
- Switches
- Accessories
- Pro-Wired Jacks
Pickups
Designed to work with most standard pickups. Special pickup wires are not required.
- Single Coils - Use 250k Volume
- Humbuckers -Use 500k Volume
- P90s - Use 500k Volume
Does NOT suit Active / Battery powered pickups

Note - Vintage braided pickup wires such as those found on vintage and re-production humbuckers are not a good match for the solder-less connectors on some Flex-Series products.
Shaft Length & Size
- Short Shaft: Pickguard / Control Plate Mount Only
- Long Shaft: Rear / Cavity Mount Only
  - Standard Long Shaft: Min Body Thickness 33mm
  - Push / Pull Long Shaft: Min Body Thickness 45mm
- Hole Size: 9.54mm
Ream smaller 'Metric' holes to 9.54mm
Knobs
Compatible with US spec split, or solid shaft knobs
- Split Shaft 24 Spline
- Solid 1/4" Knobs with included shaft adapter / brass bushing
Not Compatible with smaller 'Metric' size knobs
