  • Custom 4-Way for Tele®
1 5

ObsidianWire®

T4 Custom 250k

Custom 4-Way for Tele®

Available in Canada at:

Solo Guitars - ObsidianWire Dealer Canada

Super Easy, Solder-less Install
Key Features:

  • Custom '4-Way' Control Layout
  • Play Pickups in Humbucker Mode (Series)
  • Crystal Clear Tone (Treble Bleed)
  • Smooth Tone Control
  • Fits Fender® Telecaster®
  • Fits Squier® Telecaster® with adjustments
  • Includes Pro-Wired Jack

More information View images
ObsidianWire solderless install logo

Super Easy, Solder-less Install
All Obsidian® Pro-Wired™ Electronics are super easy to install, and allow for solder-less pickup changes with Obsidian® Plug, Play & Enjoy connectors.



CUSTOM 4 WAY WIRING HARNESS FOR TELECASTER®

Fourth Position = Humbucker Mode ~ Requires Three Wire Neck Pickup Mod


The Obsidian® Custom Telecaster 4-Way wiring harness for adds a tasty fourth switch position to make your Tele scream. The neck and bridge pickups are able to work in series to provide a more powerful humbucker like tone. You can use this position for stronger rhythm and screaming leads.

Your Telecaster will retain all of the traditional switch positions, and the familiar master tone and volume controls.

CRYSTAL CLEAR TONE (Treble Bleed)

Retain clarity at lower volumes. To make your tone crystal clear at lower volumes we include an Obsidian® Custom spec treble bleed mod. This prevents tone 'muddiness' at low volumes by allowing high frequencies to pass along a separate path to your amp, rather than being stopped short by the increasing resistance at the volume control.

SMOOTH CONTROL

Even tone and volume control all the way from zero to ten. Obsidian® tone and volume controls incorporate carefully selected and custom-built components, as well as our own clever mods to smooth out the taper of your tone and volume controls, so you get a more even roll off all the way from zero to 10.

TELECASTER 4 WAY SWITCH POSITIONS:

1: Neck & Bridge in Series (Humbucking)
2: Neck
3: Neck & Bridge in Parallel (Traditional Tele)
4: Bridge

ObsidianWire 4-Way Telecaster Wiring Harness
Telecaster 4-Way Switch Wiring Harness by ObsidianWire
Obsidian Wire | Custom 4-Way for Tele® | Buy direct from the ObsidianWire Strore
Demo video for the ObsidianWire 4-way wiring harness for Telecaster Video demo of the ObsidianWire 4-way solderless wiring harness for Tele
Custom 4-Way for Tele®

Custom 4-Way Wiring - for SS Telecaster®

The Custom 4-Way for Tele®

  • Custom '4-Way' Control Layout
  • Play Pickups in Humbucker Mode (Series)
  • Crystal Clear Tone (Treble Bleed)
  • Smooth Tone Control
  • Fits Fender® Telecaster®
  • Fits Squier® Telecaster® with adjustments
  • Includes Pro-Wired Jack

Details

Description

ObsidianWire solderless install logo

Super Easy, Solder-less Install
All Obsidian® Pro-Wired™ Electronics are super easy to install, and allow for solder-less pickup changes with Obsidian® Plug, Play & Enjoy connectors.



CUSTOM 4 WAY WIRING HARNESS FOR TELECASTER®

Fourth Position = Humbucker Mode ~ Requires Three Wire Neck Pickup Mod


The Obsidian® Custom Telecaster 4-Way wiring harness for adds a tasty fourth switch position to make your Tele scream. The neck and bridge pickups are able to work in series to provide a more powerful humbucker like tone. You can use this position for stronger rhythm and screaming leads.

Your Telecaster will retain all of the traditional switch positions, and the familiar master tone and volume controls.

CRYSTAL CLEAR TONE (Treble Bleed)

Retain clarity at lower volumes. To make your tone crystal clear at lower volumes we include an Obsidian® Custom spec treble bleed mod. This prevents tone 'muddiness' at low volumes by allowing high frequencies to pass along a separate path to your amp, rather than being stopped short by the increasing resistance at the volume control.

SMOOTH CONTROL

Even tone and volume control all the way from zero to ten. Obsidian® tone and volume controls incorporate carefully selected and custom-built components, as well as our own clever mods to smooth out the taper of your tone and volume controls, so you get a more even roll off all the way from zero to 10.

TELECASTER 4 WAY SWITCH POSITIONS:

1: Neck & Bridge in Series (Humbucking)
2: Neck
3: Neck & Bridge in Parallel (Traditional Tele)
4: Bridge

Specs

BUILT IN HOUSE WITH

  • Potentiometers: Obsidian® Custom CTS® Pots 250K (+/-10%) - Solid Shaft 1/4"
  • Capacitors: (150 Series Polyester Film 0.022UF) (+/-5%)
  • Switch: Genuine Oak® 3 Way Switch
  • Jack: Pro-Wired Switchcraft® J11 Mono // OR Pure Tone® Mono Multi-Contact 1/4 in

More Info

Compatibility

MADE TO FIT

  • Fits: Fender® US & MIM Telecaster® - Direct Fit // Right Hand Guitar Only
  • Fits: Fender® Japan Telecaster® - Replace control plate & knobs
  • Fits: Squier® Telecaster® - Replace control plate & knobs
  • Knobs: Requires US Spec 1/4" Solid Shaft Knobs
  • Control Plate: Use Genuine Fender or Obsidian® plate only - Other aftermarket plates will NOT fit
  • Pickups: Built for two single coil pickups. Requires three wire (2x ground & 1x hot) neck pickup or a three wire mod. Wire instructions are provided, but a solder join is required.

DOES NOT FIT

  • Does NOT Fit: Thinline telecaster, or any guitar not specified above

Install

For install help and other resources please go to our Info Hub.

Shipping

US Based Fulfillment:

We ship from Michigan, USA.

Please note that due to the way in-state taxes are collected, we cannot ship website orders within Michigan state. If you are based in Michigan, please order through our Amazon store here as this is set up to collect the required sales taxes. Apologies for any inconvenience caused.

Canada

Shipping method: Business days: Price (US$ Aprox.)
ECONOMY POST 7 - 21 8.99
DHL PACKET 5 - 10 13.99



Taxes and duties

Obsidian® DOES NOT pay duties, taxes or customs clearance charges.

Duties and taxes charged by your local customs agency, will be your own responsibility.

If you live outside the USA, we recommend checking with your own country's customs agency what these may be prior to ordering.

If you are concerned, consider ordering from dealer near you
